2-Pin CFL Lamps

The Different Types of 2-Pin PL Lamps

The designation of a 2-pin PL lamp depends on the specific lamp base (socket) and the shape of the lamp. It is important to know the correct socket for a proper replacement.

Operation and Installation of Traditional 2-Pin PL Lamps

An essential aspect of 2-pin PL lamps is their reliance on a conventional (electromagnetic) ballast and a starter. The ballast regulates the power supply to the lamp, while the starter provides a brief voltage pulse to initiate the gas discharge in the lamp. Without these components, the lamp will not ignite or operate correctly. For technicians, it's important to note that a faulty ballast or starter is often the cause of a non-working PL lamp, not the lamp itself.

How to Replace a 2-Pin PL Lamp:

1. Always switch off the power supply to the fixture before starting. This is an important safety measure.

2. Remove the old 2-pin PL lamp by gently pulling it straight out of the socket. You may need to wiggle it slightly if it's stuck.

3. Check the socket type (for example, G23, G24d-1), and, if present, replace the starter. The starter is a small cylindrical component located next to the lamp.

4. Insert the new 2-pin PL lamp into the socket by pushing the pins straight into the openings until it clicks into place. Make sure the lamp is properly oriented.

5. Switch the power back on to check if it works.

Switching to LED: A Sustainable Alternative

Traditional 2-pin PL lamps are gradually being phased out due to new European regulations focusing on energy efficiency and environmental friendliness. LED replacements offer a future-proof solution with various benefits:

• High energy savings: LED 2-pin lamps use significantly less power, yielding up to 70% savings on energy costs. For example, a 9W LED PL-C can replace a traditional 26W PL-C.

• Longer lifespan: LED lamps last up to five times longer than traditional PL lamps, often up to 50,000 burning hours. This reduces replacement frequency and associated maintenance costs.

• Improved light quality: LEDs offer stable, flicker-free light and are available in a wide range of color temperatures (Kelvin) with a high color rendering index (CRI > 80), resulting in true-to-life colors.

• Environmentally friendly: LED lamps contain no mercury or other harmful substances, making them safer for the environment and easier to recycle. Many LED PL replacements are also made of shatterproof plastic.

• Instant full brightness: LED lamps reach full brightness instantly with no warm-up time.

Finding the Right 2-Pin LED PL Replacement

When switching to LED, it is crucial to select a replacement that is compatible with your existing fixture and meets your lighting needs. Pay attention to the following points:

1. Socket (lamp base): The LED replacement must have the same 2-pin socket as your current PL lamp (e.g., G23 for PL-S, G24d-x for PL-C). This is usually indicated on the lamp itself.

2. Replacement wattage: Although LEDs have a lower wattage, it's important to check which traditional wattage the LED lamp replaces. This ensures similar light output.

3. Luminous flux (Lumens): The lumen value indicates the amount of light. Compare this value to ensure adequate brightness.

4. Light color (Kelvin): Choose the Kelvin value that suits the desired atmosphere and application.

   • Warm white (2700K–3000K): Suitable for atmospheric areas such as hallways, waiting rooms, hospitality environments, and homes.
   • Cool white (4000K): Suitable for functional spaces where concentration is required, such as offices, schools, warehouses, and shops.
   • Daylight white (6500K): Suitable for detailed work, such as laboratories or workshops.

5. Type of ballast: Some LED 2-pin PL lamps are 'plug-and-play' and work directly with the existing conventional ballast. Others require modification, with the ballast removed and the LED lamp connected directly to the mains (ballast bypass). Always check the product information. For complex situations or larger projects, it's advisable to consult an installer.

Applications of 2-Pin PL Lighting and LED Alternatives

Historically, 2-pin PL lamps have been widely used in compact fixtures across various environments. With the transition to LED, these fields of application remain relevant, now with the added benefits of LED technology:

• General lighting: Frequently used in hallways, stairwells, toilets, and reception areas in offices, hotels, and public buildings.

• Downlights: Many 2-pin PL lamps are designed for recessed ceiling installation (downlights) in shops, showrooms, and homes. LED downlights offer an efficient upgrade here.

• Orientation and safety lighting: In situations where continuous lighting is needed, such as emergency lighting or ambient lighting in areas that require orientation.

• Kitchens and bathrooms: Some fixtures in these spaces are equipped with 2-pin PL lamps.

Responsible Disposal of 2-Pin PL Lamps

Because traditional 2-pin PL lamps contain mercury, it is important not to dispose of them with regular waste. Take them to a local recycling station or a special collection point for discarded electrical and electronic equipment (WEEE). This way, materials are recycled and harmful substances handled safely.
